Product Features

The Universal Frequency-to-Digital Converter (UFDC-1) is a fully digital CMOS integrated circuit based on novel patented methods for frequency, period, its ratio, duty-cycle and phase-shift measurements. By using this IC it is possible to build a wide variety of digital, smart sensors and intelligent sensor systems. The device represents a high-resolution conversion for data acquisition systems designed to support all range of frequency-time domain and digital sensor applications. It offers high performance with flexibility and requires minimum possible number of external components.

The UFDC-1 can be easy included into digital environment, controlled by an external microcontroller (slave mode) or work independently as a separate measuring unit without an external control (master mode). The function selection can be configured in both software and hardware. The IC converts frequency-time domain signals into digital domain and provides interface to microcontroller, DAQ or sensor system to read these digital results. resolution and programmable accuracy during the non-redundant conversion time.

Part Descriptions

The UFDC-1 has 16 measuring and one generating modes. The measuring mode can be hardware selected by using four selection external pins M0-M2 and the relative error by using four selection pins N0-N2 (RS232 master communication mode). The mode and accuracy can be also selected by using any of three possible interfaces (slave communication mode). A communication interface type (RS232, SPI or I2C) can be automatically selected according to the circuit connection.
